PVC glass-fiber reinforced pipe production line

Φ12-Φ50 soft PVC glass-fiber pipe production line1. Auto plastic loader 1 1) model:ZL-AL300 2) motor power:0.75KW 2. SJ65/28 Single Screw Extruder 1) Screw diameter:φ65 mm 2) L/D=28:1 3) Main motor power:18.5kw (D.C.) 4) Heating power for barrel:4kWX4=16kw 5) Heating zone for barrel :4zones,Al cast heater 6) Cooling fan for barrel:0.18KWX4 7) Reducer:ZLYJ173 hard surface gear box,cooling by circulated oil pump. 8) Material of screw and barrel:38CrMoALA 9) Special designed screw for soft PVC 10) Ni cover thickness:0.5 0.7mm 11) Surface hardness:HV800 900 12) PLC control, Eurothern speed control. Human-computer interface, 10.4’ LCD. Modom long-distance data diagnostic system; NEWNET-W internet communication connecting style. 3. Die1 1) 45# steel with forged, tempering treatment, and precision processed. 2) From φ12mm, φ14mm, φ16mm, φ20mm, φ25mm, φ32mm, φ38mm, φ45mm, φ50mm 4. Cooling tank 1 1) Material of tank: stainless steel 2) length: 3000mm 3) spray cooling, material of channel is stainless steel 4) Tank can be three-dimensional moved. 5. Haul-off 1 1) Model: QY-I 2) Rubber slipping-prevent slab 3) control power:2.2kw 4) speed controlled by FUJI converter 5) speed: 2-18m/min 6. Yarn Machine 1) motor power: 3kw 2) quantity of woof:12X2 3) quantity of meridian :6 4) special gearbox which is anti-direction rotate 5) adopt semi-round safe protector 7. Oven 1) Length:1500mm; 2) Heating power:6kW; 3) Fan power:0.37kWX2 8. Auto plastic loader 2 1) model:ZL-AL300 2) motor power:0.75KW 9. SJ75/28 Single Screw Extruder 1) Screw diameter:φ75 mm 2) L/D=28:1 3) Main motor power:22kw (D.C.) 4) Heating power for barrel:5kWX4=20kw 5) Heating zone for barrel:4zones,Al cast heater 6) Cooling fan for barrel:0.18KWX4 7) Reducer : ZLYJ173 hard surface gear box,cooling by circulated oil pump. 8) Material of screw and barrel:38CrMoALA 9) Special designed screw for soft PVC 10) Ni cover thickness:0.5 0.7mm 11) Surface hardness:HV800 900 12) PLC control, Eurothern speed control. Human-computer interface, 10.4’ LCD. Modom long-distance data diagnostic system; NEWNET-W internet communication connecting style. 10. Die 2 1) 45# steel with forged, tempering treatment, and precision processed. 2) From φ12mm, φ14mm, φ16mm, φ20mm, φ25mm, φ32mm, φ38mm, φ45mm, φ50mm 11. Cooling tank 2 1) Material of tank: stainless steel 2) length: 3000mm 3) spray cooling, material of channel is stainless steel 4) Tank can be three-dimensional moved 12. Haul-off 2 1) Model: QY-I 2) Rubber slipping-prevent slab 3) control power:2.2kw 4) speed controlled by FUJI converter 5) speed: 2-18m/min 13. Coiler 1) Single coiler 2) Moment motor:16NM
